Portable Digital Rebound Leeb Hardness Tester HARDY P130 HL, HB, HRB, HRC, HRA, HV, HS Built-in Printer USB PC Software for Steel Alloy

1 Features

●Ultra-thin shell, more easily to hold

●Suitable for multiple impact device and 6 types of hardness scales are available for various applications

●Large and clear digital display

●Ultra-low power dissipation with three AAA batteries powered

2 Technical Specification:

●Hardness Scales:HL, HRC,HRB,HV,HB,HS

●Test Precision:HLD:±6 HRC:±1 HB:±4

●Standard Impact Device: impact device of Type D

●Upper / Lower Limits Setting:(170-960)HLD, (17.9-69.5)HRC, (19-683)HB, (80-1042)HV, (30.6-102.6)HS, (13.5-101.7)HRB

●Optional Impact Device: D/ C /DC / D+15 / DL/ G

●Number of Impact Devices Equipped With One Time: any

●PC Interface: USB 2.0

●Language: Chinese/English

●Screen Display: 128X64 dot matrix LCD, backlight and adjustable contrast

●Measuring Direction:360°(down, inclined down, level,inclined up and up)　

●Data Memory :200 readings

●Maximum Hardness of The Measured Work Piece: 940HV(for D,DC,DL,D+15,C impact device)

●Radius of Rurvature of The Measured Work: Rmin=50mm(If using Alien supporting ring, Rmin=10mm)

●Recognition Function:Recognize the type of the impact device by itself

●Measurable Material:Steel and cast steel, alloy tool steel, stainless steel, gray cast iron, nodular cast iron, aluminum casting alloy, copper zinc alloy(brass), copper tin alloy(bronze), fine copper

●Power Supply: 1.5V AAA battery ( 3 PCS)

●Working time: about 150 hours

●Shape Size: 155mm*68mm*27mm
