Programmable Environmental Test Chamber Constant Temperature For Humidity Testing

    Buy cheap Programmable Environmental Test Chamber Constant Temperature For Humidity Testing from wholesalers

    Buy cheap Programmable Environmental Test Chamber Constant Temperature For Humidity Testing from wholesalers
    • Buy cheap Programmable Environmental Test Chamber Constant Temperature For Humidity Testing from wholesalers

    Programmable Environmental Test Chamber Constant Temperature For Humidity Testing

    Ask Lasest Price
    Brand Name : Pride
    Model Number : PTH-80A
    Price : negotiation
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Delivery Time : 10-15 work days
    • Product Details
    • Company Profile

    Programmable Environmental Test Chamber Constant Temperature For Humidity Testing

    Programmable Environmental Test Chamber Constant Temperature For Humidity Testing


    ● THC Series of Programmable Constant Temperature and Humidity Testing Chamber are designed to accurately produce the temperature and humidity conditions required for applications such as stability studies, package testing, TAPPI, MIL-SPEC and vapor transmission.
    ● It is applied to test for the industries of pharmaceutical development and manufacturing, electronic components, food, semiconductor, paper and pulp, and wherever precise humidity and temperature replications are required.
    ● THC microprocessor controller TH500 is a user-friendly system that provides optimum accuracy and control. The display is equipped with direct readings in both temperature and humidity. It also features 100--segment programming for automatic cycling and ramping and soaking excursions. High-low or deviation alarms as well as digital communications ports are standard features.


    THC Specification:


    Model No.PTH-80APTH-150APTH-225APTH-416APTH-800APTH-1000APTH-80APTH-150BPTH-225BPTH-416BPTH-800BPTH-1000B
    Internal Dimensions
    (mm)
    W4005005007001000100040050050070010001000
    H5006007508501000100050060075085010001000
    D40050060070080010004005006007008001000
    External Dimensions (mm)W9301030108012301530153093010301080123015301530
    H131014101620166018101810131014101620166018101810
    D81091011201210131015108109101120121013101510
    Volume (L)801502254168001000801502254168001000
    Temperature Range0℃~100℃(150℃)-20℃~100℃(150℃)
    The Evenness Of Humiture Distribu tion±0.5℃ ±3%RH± 1 ℃ ± 5 %R H±0.5℃ ±3%RH± 1 ℃ ± 5 %R H
    Temperature Rising Speed0℃~100℃ about 20min-20℃~100℃ about 35min
    Temperature Falling Speed20℃~0℃ about 20min20℃~20℃ about 45min
    Freezing System1PC of fully sealed air cooling system
    Humidity Range20%~98%RH
    Humiture Stability±0.2℃ ±2%RH
    Humiture AdjustmentAuto balancing temperature and humidity adjustment
    Outside MaterialsStainless steel sus # 304
    Inside MaterialsStainless steel sus # 304
    Humidifying SystemSurface evaporation, humidifier with stainless steel heating and equipped with a power off device when humidifier wants water and an over-temperature protection device.
    Thermal MaterialHeat preserved by rock wool and hardened pu foaming
    Heating SystemHeater with stainless steel dissipation
    Circulatory Syste mConvection by fan forced circulatory system
    Dehumidifying SystemFreezing dehumidifying system
    Water Supplying SystemThe advance water tank, fully automatic water supplying control, device for reuse through recovery and circulatory filtering plus a warning device for insufficient water.
    Safety DevicesLeakage and overload protection device, compressor overload protection device, power off device for over-temperature and over humidity, water insufficient protection device, overtemperatureprotection device for humidifier and the protection device for limit of temperature.
    Standard DeliveryTwo sets of the adjustable SS plate, the vacuum glass windows, the test hole, a lamp inside the operation room and a movable indicator.
    Optional AccessoriesRecorder
    PowerAC220V/50, AC110V/60HZ

    THC Specification:

    ModePTH-80CPTH-150CPTH-225CPTH-416CPTH-800CPTH-1000CPTH-80DPTH-150DPTH-225DPTH-416DPTH-800DPTH-1000D
    Internal Dimensions (mm)W4005005007001000100040050050070010001000
    H5006007508501000100050060075085010001000
    D40050060070080010004005006007008001000
    External Dimensions (mm)W9301030108012301530153093010301080123015301530
    H131014101620166018101810131014101620166018101810
    D81091011201210131015108109101120121013101510
    Volume (L)801502254168001000801502254168001000
    Temperature Range-40℃~100℃(150℃)-70℃~100℃(150℃)
    The Evenness Of Humiture Distribution±0.5℃ ±3%RH± 1 ℃ ± 5 %R H±0.5℃ ±3%RH± 1 ℃ ± 5 %R H
    Temperature Rising Speed-40℃~100℃ about 40min-70℃~100℃ about 60min
    Temperature Falling Speed20℃~40℃ about 60min20℃~70℃ about 90min
    Freezing System2PCS of fully sealed air cooling syste m3PCS of fully sealed air cooling system
    Humidity Range20%~98%RH
    Humiture Stability±0.2℃ ±2%RH
    Humiture AdjustmentAuto balancing temperature and humidity adjustment
    Outside MaterialsStainless steel sus # 304
    Inside MaterialsStainless steel sus # 304
    Humidifying SystemSurface evaporation, humidifier with stainless steel heating and equipped with a power off device when humidifier wants water and an over-temperature protection device.
    Thermal MaterialHeat preserved by rock wool and hardened pu foaming
    Heating SystemHeater with stainless steel dissipation
    Circulatory Syste mConvection by fan forced circulatory system
    Dehumidifying SystemFreezing dehumidifying system
    Water Supplying SystemThe advance water tank, fully automatic water supplying control, device for reuse through recovery and circulatory filtering plus a warning device for insufficient water.
    Safety DevicesLeakage and overload protection device, compressor overload protection device, power off device for over-temperature and over humidity, water insufficient protection device, overtemperatureprotection device for humidifier and the protection device for limit of temperature.
    Standard DeliveryTwo sets of the adjustable SS plate, the vacuum glass windows, the test hole, a lamp inside the operation room and a movable indicator.
    Optional AccessoriesRecorder
    PowerAC220V/50, AC110V/60HZ
